Technical parameters:
(1)Overall dimension (mm)：2100*650*1660 (including hopper)
(2)Weight (KG)：700
(3)Screw diameter (mm)：Φ50
(4)Screw length-diameter ratio：28:1
(5)Production capacity (Kg/h)：15-35
(6)Screw speed (r/min)：10-90
(7)Power supply (V)：380
(8)Center height (mm)：1000
(9)Motor power (KW)：11
(10)Frequency converter power (KW)：11
(11)Maximum total power (KW)：20
(12)Heating temperature zone：5 zones
